Aerial Photography 5 Inch LCD TFT Monitor, No Blue screen


Advanced Features:

*NO Blue Screen
*Default Display View
*350cd/m high brightness
*Supports Composite Video RCA Input
*Display Resolution up to 1920x1440 Pixels
*16: 9 or 4: 3 Adjustable Display Ratio
Desciption5" FPV monitor for aerial photography
Model:FPV-500A
Brightness:350cd/m²
Dot Resolution:800x480 pixels (max to1920×1440)
Contrast Ratio:500:1
Aspect Ratio:16:9
Backlight:LED
Response time:10ms
Support video format:NTSC M, PAL M, NTSC BG, PAL N, NTSC DK, PAL DK, PAL I and SECAM BG.
Viewing Angle:70°/70°(L/R) 50°/70°(U/D)
Input Voltage: DC 6-24V
Input Signals:Video,Audio,Side Earphone Jack
Output Signals:Built in speaker
Power Consumption:≤7W
workingTemperature:-20ºC~55ºC
storage Temperature:-30ºC~65ºC
Install Way:"1/4"-20 Thread and VESA mounting socket(75mm)
Unit Size:146L × 100W ×29.5H (mm)
Unit Weight:260g
340g(With sun shade )
